Product Range	Compact Panel	Watts Delta T60°C	702
Watts Delta T50°C	555	BTU Range T60°C	2000 - 2499
BTU Range T50°C	1500 - 1999	BTU Delta T60°C	2394
BTU Delta T50°C	1894	Width (mm)	600
Schema classification	Radiators & Towel Rails	Product Type (Web)	Radiator
Colour	Matt Anthracite	Net Weight (kg)	9.53
Item Description	Type 11 Compact Panel Radiator 600 x 600	Height (mm)	600
EAN	5056518022299	Categorisation	Radiators
Supplied with fixings	1	Manufacturers Warranty (years)	10
LENGTH (MM)	50	Material	Mild Steel

PLEASE NOTE THAT DUE TO CURRENT COVID-19 GUIDELINES OUR DELIVERIES MAY INCUR DELAYS

Standard Delivery typically take between 2-5 working days. Working days are Monday – Friday excluding bank holidays.
Our partners at DPD will typically send you an email within 24 hours of your delivery detailing a time of when your parcel should arrive. These are subject to external factors outside of our control that may delay your order such as dangerous weather conditions.


Delivery Within Ireland
We currently deliver to all 32 counties in Ireland and Northern Ireland on the main land only.


Republic of Ireland
Standard Delivery = €6.99
Larger Bulky Items =€55.00


Northern Ireland
Standard Delivery = €35.00
Larger Bulky Items =€90.00


What is our Returns Policy/ I Have received the wrong items?

If the error is on our side for example you have been sent the wrong stock or the item arrives damaged, contact us and we will arrange for a collection with dpd etc.  If it is a no faut return we will refund you the value of your order minus the delivery and return fee.


Click and Collect
Learn about our Click and Collect Services here
When placing and order on toplinebolands.ie you will be given the option to choose to click and collect at the checkout. When click and collect is selected you will be then notified when your order is processed and will endeavour to let you know as soon as possible when your item(s) will be ready for collection.

PLEASE NOTE:  The average time for orders to be processed is 2 hours.

Please bring proof of purchase either via a physical printed copy or alternatively a digital copy on your phone in order for our staff to double check your order details and finalise your collection.

We also offer a contactless Click and Collect. This will be done through having two designated click and collect parking slots in the back of the store. When you arrive you simply call the number on the signage and the goods will be brought out to your car.

In replace of this you will be also able to come in store in order to collect you click and collect.

Should you have any questions still not answered here. Please email our customer service team at  orders@toplinebolands.ie

so we can assist you further.

  Tested to BS EN 442 standards.

• Manufactured in automatic production lines.

• Hot water central heating systems only.

• Max operating pressure 4 bars.

• Complete with fitted top grill & side panels.

• Radiators have 4 x 1/2“ connections.

• Powder coated in RAL 9016 Gloss White.

• Installation kit included in packaging.

• 10 Year Manufacturer’s Warranty*

*With conditions

 All measurements are in Height by Width.

• Heat outputs based on Delta ΔT 50°C & Delta ΔT 60°C.

• Radiators are only suitable for two-pipe installations.

• For indirect heating systems only.

• Pipework installation is recommended after receipt of radiator.

• High quality mild steel material.

• Air vent (bleed valve) and blanking plug included in installation kit.

• Bottom opposite tappings are the width of the radiator and 38 or 50mm off the wall.

• Vertical tappings are approx. 55mm less than the height of the radiator and 38 or 50mm off the wall.

• Price includes radiator and wall fixing sets, valves and accessories are extra

.

 Our compact panel radiators are individually tested and supplied complete with a 10 Year Manufacturer’s Warranty against any manufacturing or material fault. All our compact panel radiators have a working pressure of 4 Bars.

 Compact panel radiators must be installed by a qualified engineer. Instruction manual is to be followed to avoid any issues during installation.

• Consider using an Eastbrook valve set to get the perfect colour match. Please
click here
 to browse our radiator valve ranges.

• Have your system vented properly. A general cause of corrosion and leak problems are due to trapped air in the system.

• Make sure that the drain points are at lowest in the system and your system is thoroughly flushed before commissioning.

• System must be clean of residues such as metal, flux etc, this can cause pin holes.

• Do not over pump the system which will cause negative pressure aeration that can also cause corrosion.

• It is recommended that an appropriately approved corrosion inhibitor mist be subsequently added to the system in order to protect the radiator and other parts of the system to promote extended operating lifespan. Please ensure that, when adding inhibitor, not to underdose or overdose and follow the inhibitor instructions. The Ph level of the system water should be between 6.5 and 7.5

• If the system water is too acidic then the metals in the system would corrode. If the system water too alkaline, then there is higher risk of electrolysis.

• Our compact panel radiators come with an instruction manual. Please follow the basic guidance above and in the instructions to protect your 10 year manufacturer’s warranty and trouble free operating lifespan of your radiator.
